Description
| Code | Description | Head | Plug |
| BOE 8000.550 | BM-800/I/PL | Binocular | Euro |
| BOE 8000.551 | BM-800/I/PL | Binocular | US |
| BOE 8000.560 | BM-800/T/I/PL | Trinocular | Euro |
| BOE 8000.561 | BM-800/T/I/PL | Trinocular | US |
BOECO Laboratory Binocular Microscope BM-800
| Specification | |
| Optical System: | Infinity corrected system, field diameter 22 mm |
| Vieving Head: | Bin- or Trinocular compensation free head, 30° inclined, 360° rotatable, Interpupillary distance 48 – 75 mm |
| Nosepiece: | Backward quintuple revolving nosepiece |
| Eyepiece: | Larger viewing area with extra wide field eyepiece EWF 10X /22 mm |
| Objectives: | BOECO Infinite corrected Plan Achromat Objectives 4x/0.10, 10x/0.25, 40x/0.65 (S), 100x/1.25 (S, Oil) |
| Stage: | Large sized double layer mechanical specimen stage. 185 x 142 mm, Moving range 75 x 55 mm, |
| Focusing: | Coaxial coarse and calibrated fine focus control, fine division 0,001 mm, Coarse stroke 37,7mm/rotation fine stroke 0,1mm/rotation, mowing Range 24 mm safety autofocus stop unit. |
| Condenser: | Swing condenser, N.A. 0,9/0,25, |
| Field diaphragm: | With aspherical condenser and Köhler Illumination |
| Illumination: | 5W LED lamp, light intensity adjustable. |
| Body /power: | Modern and ergonomic body made from die-cast aluminium with inbuilt power supply 110-240V, 50/60Hz |
| Supplied with: | Dust cover, immersion oil, green filter and instruction manual |
| Dimension: | 280 x 358 x 304/416 mm, net weight 10,0/10,4 kgs |
